CM Series
- Product Item：
CM Series
Applications and installation
centrifugal pumps with single impeller are able to offer high flow rates, provide smooth, nonpulsating delivery, and regulate the flow rate over a wide range without damaging the pump.
For the correct functioning of the pump, use clean water, or non-aggressive liquids charged with small solid impurities.
To be used in flow irrigation system in gardening, agriculture and industrial fittings.
Pumps should be installed in a covered area, protected
against the weather.
Operating limitations
Max ambient temperature up to 40℃
Max fluid temperature up to 80℃
Max pressure up to 10 bar
Construction features
Pump Body: cast iron
Motor Housing: aluminum
Shaft: 45# steel /stainless steel
Impeller: Brass
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44 /IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon
